238-4676 2384676 Speed Sensor Wheeled Excavator Spare Parts For C7.1 M318F

Product Categories
Guangzhou Anto Machinery Parts Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

238-4676 2384676 Speed Sensor Wheeled Excavator Spare Parts For C7.1 M318F

  • 1
  • 2
  • 3

Brand Name : OEM

Model Number : 238-4676 2384676

Place of Origin : China

MOQ : 1 PCS

Price : Negotiable

Payment Terms : T/T, D/P, D/A,Western Union, L/C, MoneyGram

Supply Ability : 100-2000

Delivery Time : 3-7 working days

Packaging Details : Wooden box for heavy parts, paper carton for light parts

Engine model : C4.4 C7.1

Machine model : M325D L MH M325D MH M318F

Application : Excavator, Material Handler

Product name : Speed Sensor

Part number : 238-4676 2384676

Packing : Standard Export Carton

Contact Now

  • 238-4676 2384676 Speed Sensor Wheeled Excavator Spare Parts Fit For C7.1 M318F

  • Specification
Name Speed Sensor
Parts No 238-4676 2384676
Machine Model M325D L MH M325D MH M313C M313D M315C M315D
Category C A T Spare Parts
Lead time 1-3 DAYS
Quality Brand new, OEM quality
MOQ 1 PCS
Means of transport By sea/air, DHL FEDEX UPS TNT EMS
Packing As request or standard packing

  • Compatible models

EXCAVATOR M325D L MH M325D MH
MATERIAL HANDLER MH3037
WHEELED EXCAVATOR M313C M313D M315C M315D M315D2 M316C M316D M317D2 M318C M318C MH M318D M318D MH M322C M322D M322D MH M325C MH M330D Cat.er.pillar.

  • More other sensor parts fit for C A T machine
3116342 SENSOR-PRESSURE
120M, 12M, 2470C, 320D GC, 320D L, 323D L, 420E, 430E, 450E, 553C, 559, 613G, 914G, 924H, 924HZ, 928H, 928HZ, 938H, 953D, 963D, AP-600D, AP-655D, AP1000E, AP1055E, AP555E, BG500E, BG600D, BG655D, C4.4...
2380120 SENSOR GP-SPEED
120M, 120M 2, 12M, 2384C, 2470C, 2484C, 2570C, 2670C, 311D LRR, 312D, 312D L, 312E, 312E L, 313D, 314D CR, 314D LCR, 314E CR, 314E LCR, 315D L, 316E L, 318D L, 318E L, 319D, 319D L, 319D LN, 320D, 320...
2746719 SENSOR GP-PRESSURE
120K, 120K 2, 12K, 12M, 12M 2, 12M 3, 12M 3 AWD, 140K, 140K 2, 140M, 140M 2, 140M 3, 140M 3 AWD, 14M, 160K, 160M, 160M 2, 160M 3, 160M 3 AWD, 16M, 2290, 2390, 2391, 2491, 24M, 2590, 2864C, 324D, 324D ...
2766793 SENSOR GP-PRESSURE
120K, 120K 2, 12K, 12M, 140K, 140K 2, 140M, 140M 2, 160K, 160M, 160M 2, 2290, 2390, 2391, 2491, 2590, 324D, 324D FM, 324D FM LL, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 326D L, 32...
2482169 SENSOR GP-PRESSURE
120K, 120K 2, 12K, 12M, 140K, 140K 2, 140M, 140M 2, 160K, 160M, 160M 2, 2290, 2390, 2391, 2491, 2590, 324D, 324D FM, 324D FM LL, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 326D L, 32...
2968060 SENSOR GP-PRESSURE
120K, 120K 2, 12K, 12M, 140K, 140K 2, 140M, 140M 2, 160K, 160M, 160M 2, 2290, 2390, 2391, 2491, 2590, 324D, 324D FM, 324D FM LL, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 326D L, 32...
1636700 SENSOR GP-FUEL LEVEL
1090, 1190, 1190T, 1290T, 1390, 2290, 2390, 2391, 2491, 312C, 312C L, 312D, 315C, 315D L, 318C, 319C, 319D, 319D LN, 320C, 320C FM, 320C L, 320D, 320D FM, 320D L, 320D LN, 321C, 321D LCR, 322C, 322C F...
2218859 SENSOR AS-PRESSURE
311C, 311D LRR, 312C, 312C L, 312D, 312D L, 312D2, 312D2 GC, 313D2, 314C, 314D CR, 314D LCR, 315C, 315D L, 318C, 319C, 319D, 319D L, 319D LN, 320C, 320C FM, 320C L, 320D, 320D FM, 320D FM RR, 320D GC,...
2905825 SENSOR GP-PRESSURE
924G, 924GZ, 924H, 924HZ, 928H, 928HZ, 930G, AP-600D, AP-655D, AP1000E, AP1055E, AP555E, BG1000E, BG1055E, BG500E, CW-34, IT28G, M313C, M313D, M315C

  • Catalog parts list
Pos. Part No Qty Parts name Comments
1 238-4672 [1] PISTON AS
333-8007 [1] SEAL-RING
2 238-4673 [1] SPRING
3 238-5087 [1] SEAL-O-RING
4 238-4674 [1] HOUSING-DRIVE
5 5W-5475 [3] SEAL-O-RING
6 6V-8675 M [5] BOLT (M12X1.75X35-MM)
7 107-5665 [2] SEAL-O-RING
8 238-4675 [1] HOUSING GP-TRANSMISSION
8A. 238-4678 [8] PLUG
9 095-0882 [1] PIN-SPRING
10 238-4676 [1] SENSOR AS-SPEED (TRANSMISSION OUTPUT)
7L-2180 [1] SEAL-O-RING
11 170-0831 [1] BOLT
12 238-4677 [2] PLUG
13 9R-3176 [2] SEAL-O-RING
14 3T-6376 J [8] PLUG
15 6T-6308 J [6] SEAL-O-RING
16 9X-0630 [3] VALVE
18 9W-4926 [2] PLUG
19 6T-6408 [2] SEAL-O-RING
20 366-1892 [1] FITTING AS
21 5W-1693 [2] WASHER (10.2X13.9X1-MM THK)
22 238-4680 [1] FITTING
23 8U-1961 [1] BALL
24 238-4682 [1] SPRING
25 238-4683 [1] BREATHER (TRANSMISSION)
26 238-4684 [12] DISC (1.6-MM THK)
27 238-4685 B [3] DISC-CLUTCH (1.2-MM THK)
238-4686 B [9] DISC-CLUTCH (1.4-MM THK)
238-4687 B [1] DISC-CLUTCH (1.6-MM THK)
30 8U-1278 [1] RING-RETAINING
31 238-4689 [1] SHIM (1-MM THK)
32 238-4690 [1] SPRING
33 238-4691 [1] RING
34 238-4692 [2] WASHER-THRUST (55X78X1-MM THK)
35 263-4911 [1] BEARING-THRUST
36 238-4694 [1] PISTON
37 238-4695 [1] SPRING
38 238-4696 [1] RING
39 238-4697 [1] RING
40 238-5088 [2] SEAL-O-RING
41 238-4698 [1] SEAL
42 169-8397 [1] RETAINER
43 8U-5983 [1] WASHER (140X190.5X11-MM THK)
44 169-8402 B [1] GEAR-DISC (2.8-MM THK)
45 8U-5988 [8] DISC-FRICTION (3-MM THK)
8U-5985 B [1] GEAR-DISC (3-MM THK)
8U-5986 B [1] GEAR-DISC (3.2-MM THK)
121-8066 B [1] GEAR-DISC (3.3-MM THK)
169-8398 B [9] DISC-CLUTCH (2.9-MM THK)
8U-5987 B [1] GEAR-DISC (3.5-MM THK)
121-8067 B [1] GEAR-DISC (3.4-MM THK)
121-8068 B [1] GEAR-DISC (3.7-MM THK)
121-8069 B [1] DISC-CLUTCH (3.8-MM THK)
121-8070 B [1] DISC-CLUTCH (3.9-MM THK)
53 238-4699 [1] PISTON
54 238-4700 [1] SPRING
55 238-4701 [1] SEAL
56 238-4702 [1] SEAL
57 238-4703 [1] SEAL
58 238-4704 [1] SEAL
59 238-4705 [2] PIN
60 291-9451 [3] PINION-PLANETARY
61 291-9452 [3] BEARING-CYLINDER ROLLER
62 375-6310 C [1] CARRIER-PLANETARY
63 238-6588 [6] PIN-SPRING
64 238-4709 [2] BEARING
65 238-5653 [3] RING-RETAINING (EXTERNAL)
66 238-4710 [1] GEAR-INTERNAL
67 238-4711 [1] BALL BEARING
68 9T-2584 [1] RING-RETAINING (INTERNAL)
69 303-4154 C [1] SHAFT-DRIVE
71 238-4714 [1] RING-CENTERING
72 238-4713 [1] RING-RETAINING
73 095-0930 [1] RING-RETAINING (EXTERNAL)
74 238-4715 [1] WASHER-SPECIAL
77 132-4295 [1] CAGE
78 238-4717 J [1] SHAFT-PUMP
79 121-8088 J [1] BALL BEARING
80 096-2323 J [1] RING-RETAINING (EXTERNAL)
81 121-8089 J [1] COVER
82 095-0934 J [1] RING-RETAINING (INTERNAL)
83 238-4718 J [1] HOUSING
84 149-5881 J [1] VALVE AS-RELIEF (DOWNSHIFT INHIBITOR)
84A. 169-8432 [1] SEAL
84B. 169-8433 [1] SEAL
85 147-5044 J [1] FILTER ELEMENT-OIL (TRANSMISSION)
86 238-4719 J [1] SEAL
87 238-4731 J [1] COVER
88 7T-0510 [2] BOLT
89 7X-2537 M [7] BOLT (M8X1.25X35-MM)
90 8T-2224 M [1] BOLT-SOCKET HEAD (M8X1.25X85-MM)
91 121-8093 J [10] WASHER (8.4X17X1.5-MM THK)
92 121-8101 J [1] SLEEVE
93 238-4721 J [1] ROTOR AS
94 121-8097 J [3] SPRING
95 121-8098 J [4] BALL
96 6V-6936 JM [3] BOLT (M6X1X22-MM)
97 121-8094 J [2] SEAL-O-RING
98 233-8732 [1] GEAR
99 238-4722 [1] PLATE
100 237-7251 [8] STUD (M10X1-THD)
101 238-4723 [1] SHROUD
102 238-4725 [1] GEAR
103 238-4726 [1] PLATE-DEFLECTOR
104 290-8580 [1] COVER-BEARING
105 110-0124 B [1] SHIM (2-MM THK)
110-0122 B [1] SHIM (1.8-MM THK)
110-0121 B [1] SHIM (1.5-MM THK)
110-0120 B [1] SHIM (1.2-MM THK)
129-9912 B [1] SHIM (1.9-MM THK)
129-9913 B [1] SHIM (1.7-MM THK)
129-9914 B [1] SHIM (1.6-MM THK)
129-9915 B [1] SHIM (1.4-MM THK)
129-9916 B [1] SHIM (1.3-MM THK)
190-8567 B [1] SHIM (1-MM THK)
190-8566 B [1] SHIM (0.9-MM THK)
190-8565 B [1] SHIM (0.8-MM THK)
190-8563 B [1] SHIM (0.7-MM THK)
190-8561 B [1] SHIM (0.6-MM THK)
5W-2074 B [1] SHIM (0.5-MM THK)
5W-2073 B [1] SHIM (0.3-MM THK)
5W-3644 B [1] SHIM (0.2-MM THK)
5W-2072 B [1] SHIM (0.1-MM THK)
193-1123 B [1] SHIM (0.75-MM THK)
193-1124 B [1] SHIM (0.65-MM THK)
125 8U-6075 [1] SEAL-LIP TYPE
126 8U-3284 [10] STUD (M12X1.75X50-MM)
127 375-4478 [1] PINION-GEAR
128 121-8117 [1] SEAL-O-RING
129 121-8129 [1] BEARING-ROLLER
130 238-4729 [1] BUSHING
131 8U-6068 B [1] WASHER (50.1X62X2.05-MM THK)
8U-6069 B [1] WASHER (50.1X62X2.1-MM THK)
8U-6072 B [1] WASHER (50.1X62X2.25-MM THK)
8U-6074 B [1] WASHER (50.1X62X2.35-MM THK)
121-8118 B [1] WASHER (50.1X62X2.4-MM THK)
121-8119 B [1] WASHER (50.1X62X2.45-MM THK)
121-8120 B [1] WASHER (50.1X62X2.5-MM THK)
121-8121 B [1] WASHER (50.1X62X2.55-MM THK)
121-8122 B [1] WASHER (50.1X62X2.6-MM THK)
121-8123 B [1] WASHER (50.1X62X2.65-MM THK)
121-8126 B [1] WASHER (50.1X62X2.85-MM THK)
153-4708 B [1] WASHER (50.1X61.8X2.9-MM THK)
153-4709 B [1] WASHER (50.1X61.8X2.93-MM THK)
153-4710 B [1] WASHER (50.1X61.8X2.96-MM THK)
153-4711 B [1] WASHER (50.1X61.8X2.99-MM THK)
153-4712 B [1] WASHER (50.1X61.8X3.02-MM THK)
370-2927 B [1] WASHER (50.1X61.8X1.95-MM THK)
147 5W-2795 [1] BEARING
148 240-4131 [1] SEAL-LIP TYPE
149 121-8116 [1] SEAL-O-RING
150 8U-6065 [1] PLATE
151 8T-4186 M [6] BOLT (M10X1.5X40-MM)
152 7X-5778 [1] SEAL-O-RING
153 109-5700 [1] SEAL-O-RING
154 5W-6370 [1] RING-RETAINING
AVAILABLE REPAIR KIT(S):
311-1217 J [1] KIT-REPAIR (GEAR PUMP)
(ALSO INCLUDES BOLTS)
B USE AS REQUIRED
C CHANGE FROM PREVIOUS TYPE
J KIT MARKED J SERVICES PART(S) MARKED J
M METRIC PART

238-4676 2384676 Speed Sensor Wheeled Excavator Spare Parts For C7.1 M318F

  • We could supply the following spare parts

1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.

2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.

3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.

4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.

5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.

6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.

  • Advantage

1. Offer Top quality & competitive products


2. Support 12-month warranty


3. 100% tested before shipping


4. Delivery in time


5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator


6. More than 15 years production and 11 years foreign trade experience


7. Professional QC team


8. Best sales team, 24 hours service

  • Packing and Shipping

Packing Details :

inner packing : plastic film for wrapping

external packing : wooden

Shipping :

within 3 days after received the payment , by air or by express or by sea on the basis of the

quantity and emergency circumstances.

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,

2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.

3. By Sea: Delivery from the Huangpu port .
