| Product name |
Planetary gear |
| Part number |
333-2991 3332991 333-2992 3332992 |
| Model |
323 |
| Category group |
Excavator Final Drive |
| MOQ |
1 PCS |
| Warranty |
6 months |
| Payment term |
T/T, Western Union, MoneyGram |
| Delivery time |
1-3 days after receiving the payment |
| Packing |
As request or standard packing |
| Means of transport |
By sea/air, DHL |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
094-0580 |
[1] |
PLATE (10-MM THK) |
|
| 2 |
094-0611 |
[6] |
WASHER (47.3X76X1-MM THK) |
|
| 3 |
096-1773 B |
[1] |
SHIM (0.15-MM THK) |
|
| |
096-1774 B |
[1] |
SHIM (0.3-MM THK) |
|
| |
096-1775 B |
[1] |
SHIM (0.4-MM THK) |
|
| |
096-1776 B |
[1] |
SHIM (0.5-MM THK) |
|
| |
096-1777 B |
[1] |
SHIM (0.6-MM THK) |
|
| |
096-1778 B |
[1] |
SHIM (0.7-MM THK) |
|
| |
096-1779 B |
[1] |
SHIM (0.8-MM THK) |
|
| |
096-1780 B |
[1] |
SHIM (1-MM THK) |
|
| |
096-1781 B |
[1] |
SHIM (1.6-MM THK) |
|
| 4 |
3E-2338 |
[2] |
PLUG-PIPE |
|
| 5 |
5P-8245 |
[16] |
WASHER-HARD (13.5X25.5X3-MM THK) |
|
| 6 |
6D-0692 |
[1] |
SEAL-O-RING |
|
| 7 |
7M-8485 |
[2] |
SEAL-O-RING |
|
| 8 |
7Y-1558 |
[1] |
SPACER (90X119.6X7.5-MM THK) |
|
| 9 |
8T-0348 M |
[28] |
BOLT-SOCKET HEAD (M16X2X50-MM) |
|
| 10 |
9X-8268 |
[28] |
WASHER (17.5X30X3.5-MM THK) |
|
| 11 |
346-5215 |
[3] |
BEARING AS |
|
| 12 |
114-1539 |
[6] |
PIN-DOWEL |
|
| 13 |
148-4715 |
[1] |
GEAR-COUPLING (55-TEETH) |
|
| 14 |
174-4874 |
[1] |
SEAL GP-DUO-CONE |
|
| 15 |
333-2989 |
[1] |
GEAR-SUN (12-TEETH) |
|
| 16 |
333-2990 |
[1] |
GEAR-SUN (18-TEETH) |
|
| 17 |
333-2991 |
[3] |
GEAR-PLANETARY (38-TEETH) |
|
| 18 |
333-2992 |
[3] |
GEAR-PLANETARY (35-TEETH) |
|
| 19 |
333-2993 |
[3] |
SHAFT |
|
| 20 |
333-2994 |
[3] |
SHAFT |
|
| 21 |
333-2995 |
[1] |
CARRIER-PLANETARY |
|
| 22 |
333-2996 |
[1] |
CARRIER-PLANETARY |
|
| 23 |
333-2998 |
[1] |
HOUSING |
|
| 24 |
455-4087 |
[1] |
HOUSING-MOTOR (LH) |
|
| 25 |
457-7977 |
[1] |
GEAR-RING (90-TEETH) |
|
| 26 |
480-6771 |
[1] |
COVER |
|
| 27 |
498-9005 |
[1] |
GASKET |
|
| 28 |
094-0584 |
[6] |
WASHER (40.3X72X1-MM THK) |
|
| 29 |
095-0891 |
[6] |
PIN-SPRING |
|
| 30 |
096-3216 M |
[2] |
SETSCREW-SOCKET (M12X1.75X12-MM) |
|
| 31 |
143-0811 M |
[16] |
BOLT (12X1.75X35-MM) |
|
| 32 |
165-5785 |
[1] |
SPACER (40X60.9X1-MM THK) |
|
| 33 |
227-6034 M |
[14] |
BOLT-FLANGE HEAD (M16X2X60-MM) |
|
| 34 |
296-6220 |
[2] |
BALL BEARING |
|
| 35 |
296-6268 |
[6] |
BEARING AS-ROLLER |
|
